SDEH-04 Horn Driver
Regular price
$39.99 USD
Regular price
Shipping calculated at checkout.
- 100W Watts RMS
-
Mounting depth: 4.7"
- Diagonal measurement: 6.25"
- Motor diameter: 3.5"
- Frequency response: 4khz-20khz
- Sensitivity: 105dB
- Impedance: 4 ohms
- Ferrite motor
- Sold individually
Nothing says “loud” like horns in a PA system. Handling 100 watts, the SDEH-04 allows you to place the music right where you want it. Extremely efficient and with incredibly low distortion, Sundown horn drivers don’t just play loud – they project, so you’re heard over everyone else.
Dimensions
| Cut-Out | 4" x 4" |
| Frame Outer Diameter | 4.5" x 4.5" |
| Mounting Depth | 4.7" |
Frequency Response
| Specification | SDEH-04 |
|---|---|
| Fs | 1.96 Hz |
| Re | 3.3 Ω |
| Qms | 6.67 |
| Qes | 15.3 |
| Qts | 4.64 |
| Outer Diameter | 4.5"x4.5" |
| Cutout Diameter | 4"x4" |
| Mounting Depth | 4.7" |
| Nominal Impedance | 4 Ω |
| Frequency Range | 4 kHz – 20 kHz |
| Magnet Material | Ferrite |
| Power (RMS) | 100W |
