- RMS 1750 watts
- Dual 2 or 4 ohm voice coils
- Optimized for small ported or bandpass enclosures
- Aluminum 3” voice coil former for superior heat dissipation
- High-temperature copper voice coil
- Double stitched surround
- Heavy-duty cast basket
- Spring-loaded terminals accept up to 8-gauge wire
- Stitched-on heavy-duty tinsel leads
- Solid pole with vent channels and aluminum shorting ring cap
- Rear gap-venting
- Top-Plate Cooling Channels
Designed to be at home in the competition lanes or playing your favorite music, the U Series is the premier “standard suspension” woofer in the Sundown lineup. A double-stacked 9.4-inch wide ferrite magnet system is coupled to a thick top plate. A thick set of shorting rings are used inside the magnets and on the pole cap, smoothing out frequency response while doubling as a heat sink and airflow guide. A custom, substantially thicker aluminum frame was designed specifically for the U Series, equipped with heat dissipation ribs. The U v.2 motor also features an extended pole piece to keep the coil under perfect control under high stress. The coil temperature is kept in check via a high-velocity solid pole / machined pole channels arrangement and a series of 16 direct air-gap vents in the back plate.
Specifications
| T/S SPECS |
UV.2 12" D2 |
UV.2 12" D4 |
| RE (Ohms) |
3.8407 |
6.0577 |
| FS (Hz) |
41.3260 |
41.9087 |
| VAS (L) |
14.7612 |
14.7535 |
| Qes |
0.4862 |
0.5870 |
| Qms |
4.7454 |
4.9022 |
| Qts |
0.4410 |
0.5242 |
| Le (mH) |
3.1858 |
4.3694 |
| BL (NA) |
27.2694 |
31.1265 |
| Mms (Grams) |
358.6438 |
356.5462 |
| Cms (uM/N) |
40.4709 |
40.4498 |
| Sens (dB @ 1w/1m) |
85.1980 |
84.4191 |
| Xmax |
30mm |
30mm |
Enclosure Specifications
| Sealed Enclosure |
1.0 cu ft |
| Ported Enclosure |
2.0 cu ft |
| Recommended Tuning |
35Hz |
| Recommended Port Area |
32 sq in |
| Displacement |
0.21 cu ft |
| Depth |
8.43″ |
| Outside Diameter |
12.84″ |
| Cut-Out |
11.2″ |
| Physical Dimensions |
