SFB-1000D Full Range Amplifier v.2

Name: SFB-1000D Full Range Amplifier v.2
Brand: Sundown Audio
SKU: A-SFBV21000
Price: 239.99 USD
Availability: OutOfStock

Regular price $239.99 USD

Regular price Sale price $239.99 USD

Unit price per

Shipping calculated at checkout.

1,000 @ 1 ohms RMS
850 @ 2 ohms RMS
500 @ 4 ohms RMS
Variable 12dB low pass filter: 80HZ – 20kHZ
Variable 12dB high pass filter: 15HZ – 1kHZ
Variable 12dB Bass Boost @ 50Hz 0-9dB
Power, protection & clipping indicators included
Thermal, voltage, speaker short, and dc-offset protection circuitry
Wired remote control with clipping indicator

The “Brazilian Style” SFB packs a powerful punch in a compact size. The flexible SFB (Sundown Full Bridge)packs a powerful punch in a compact size! Stable down to 1 ohm, the full-range SFB can be used as a subwoofer amp, or as an ideal power source for an array of P.A. speakers. If you are looking for raw power on a budget, look no further than the SFB!

Product Manual

Specifications

Recommended Fuse Rating 100A
Low Pass Filter (Variable) 80Hz-20kHz
High Pass Filter (Variable) 15Hz-1kHz
Bass Boost @ 50Hz 0-12dB
Input Sensitivity 5V Max
S/N Ratio 100dB
Working Voltage 10.5v-15.5v
Dimensions 7.25" x 5.75" x 2.50"

Specifications
