- 3in Horn driver
- Strontium Ferrite Magnet
- Die-cast Aluminium Cover
- Die-cast Aluminium Horn
- Titanium Diaphragm
- 4 Ohm
- 110 Wrms
- Exit Throat Diameter @ inch – 2
- Rated Impedance @Ohm – 4
- Power Handling Capacity @ Watt – 110
- Program Power @Watt – 220
- Sensitivity(1W/1m) @ Hz – 118
- Frequency Range @ Hz - 600-20,000
- Voice Coil Diameter @ inch - 3
- Voice Coil Material - CCAW
- Voice Coil Former Material - Kapton
- Voice Coil Winding Depth @ mm - 3
- Cutout – 6.75”
- Mounting Depth – 9.65”
- Gap Height @ mm – 3.5
- Driver Size @ in 6.7*3”
- Back Cover Material – Die-cast Aluminium
- Diaphragm Material - Titanium
- Horn Material – Die-cast Aluminium
- Product Dimension @ in – L9.5*W9.5*H10”
Key Features:
- Powerful Performance: Rated at 110W RMS and 220W program power, it handles demanding audio requirements with ease.
- Wide Frequency Range: Covers 600Hz to 20,000Hz, providing crisp, detailed sound reproduction across mid-to-high frequencies.
- Exceptional Sensitivity: Sensitivity of 118 dB (1W/1m @ Hz) ensures efficient sound output with reduced power consumption.
Robust Construction:
- Durable Materials: Titanium diaphragm for precision and long-lasting performance.
- Voice Coil Design: Equipped with a 3-inch CCAW (Copper Clad Aluminum Wire) voice coil on a Kapton former for excellent thermal resistance and durability.
- High-Quality Build: Die-cast aluminum cover and horn provide lightweight durability and efficient sound dispersion.
- Magnet: Strontium ferrite magnet ensures strong magnetic flux for reliable operation.
Specifications:
- Exit Throat Diameter: 2 inches
- Impedance: 4 Ohms
- Cutout Size: 6.75 inches
- Mounting Depth: 9.65 inches
- Driver Size: 6.7 x 3 inches
- Product Dimensions: 9.5 x 9.5 x 10 inches (L x W x H)
Additional Details:
- Voice Coil Winding Depth: 3 mm
- Gap Height: 3.5 mm
- Materials: Titanium diaphragm, Kapton former, and die-cast aluminum construction for maximum durability and performance.
