SA-Series v.3 8" Subwoofer
Regular price
$299.99 USD
Regular price
Sale price
$299.99 USD
Shipping calculated at checkout.
Notice On Packaging For Subwoofers
Sundown Audio has led the industry in quality and performance for over a decade. To improve accuracy and transparency, we have updated our subwoofer power ratings to reflect true real-world performance.
During this transition, some packaging may show previous ratings. Performance fully aligns with our current published specifications. If you have any questions about authenticity or ratings, please contact directly for confirmation.
- 600 Watts RMS/1200 Watts Peak
- Dual 2 or 4 ohm voice coils
- Vented magnetic gap with 16 chamfered vents
- Large aluminum Faraday ring for smooth acoustic response
- Patented high-strength cast aluminum frame
- Low distortion motor construction
- High-temperature voice coil wire
- Spring-loaded terminals
- Stitched-on “XL” tinsel lead wires
| Parameter | D2 Model | D4 Model |
|---|---|---|
| Re | 3.36 Ω | 6.00 Ω |
| Fs | 38.3 Hz | 40 Hz |
| Qms | 6.3100 | 4.3100 |
| Qes | 0.3240 | 0.3920 |
| Qts | 0.3090 | 0.3600 |
| Vas | 6.880 L | 7.170 L |
| Mms | 144.00 g | 126.60 g |
| Cms | 0.12 mm/N | 0.12 mm/N |
| BL | 18.940 T·m | 22.060 T·m |
| Le | 2.08 mH | 3.32 mH |
| Sd | 344.8 cm² | 344.8 cm² |
| Xmax | 16mm | 16mm |
| SPL (1W/1m) | 82.8 dB | 82.7 dB |
| Specification | D2 Model | D4 Model |
|---|---|---|
| RMS Power | 600 W | 600 W |
| Peak Power | 1200 W | 1200 W |
| Displacement | 0.08 cu ft | 0.08 cu ft |
| Mounting Depth | 6.625" | 6.625" |
| Outside Diameter | 8.375" | 8.375" |
| Cutout Diameter | 7.375" | 7.375" |
| Motor Diameter | - | 6.88 |
| Sealed Enclosure | .25-.35 cu ft | .25-.35 cu ft |
| Ported Enclosure | 0.65 cu ft | 0.65 cu ft |
| Recommended Port Tuning | 35hz | 35hz |
| Recommended Port Area | 9 sq in | 9 sq in |
| Xmax | 16mm | 16mm |
| 4th Order Sealed | .25cu ft | .25cu ft |
| 4th Order Ported | .75cu ft | .75cu ft |
| 4th Order Port Area | 15sq in | 15sq in |
| 4th Order Port Length | 6" | 6" |
