VEX-8 300 Watt Pro Audio Midrange Speaker
Regular price
$149.99 USD
Regular price
$229.99 USD
Sale price
$149.99 USD
Shipping calculated at checkout.
- Power Handling: 300 Watts RMS
- Impedance: 4/8-ohm SVC
- Vented cast frame
- 2.5-inch voice coil
- X-Max: 9mm
- Carbon fiber cone
- Excellent for Mid-bass
- High strength ferrite motor
- Dual shorting rings for smooth response
- Mounting depth : 4"
- Rear Vented
- Spring Loaded Terminals
With an enormous 2.5” voice coil and a super-efficient cooling system, the VEX handles 300 watts of power with ease. We went with real carbon-fiber cone to handle high SPL systems without breakup, and achieved a 94.3dB sensitivity by combining a large diameter, high strength ferrite motor with a neodymium pole-cap magnet! A sturdy cast-aluminum frame features extensive spider cavity vents to further increase thermal power handling. The Sundown Audio VEX is one of the loudest, best sounding high-efficiency midrange drivers in existence.
Frequency Response


| Specification | VEX-8 4 Ω | VEX-8 8 Ω |
|---|---|---|
| Fs | 97.7 Hz | 90.592 Hz |
| Re | 3.95 Ω | 6 Ω |
| Qms | 4.45 | 3.539 |
| Qes | 0.21 | 0.249 |
| Qts | 0.2 | 0.232 |
| Vas | 7.76 L | 69.41 L |
| Outer Diameter | 8.38" | 8.38" |
| Cutout Diameter | 7.20" | 7.20" |
| Mounting Depth | 4" | 4" |
| Voice Coil Diameter | 2.5" | 2.5" |
| X-Max | 9 mm | 9 mm |
| Nominal Impedance | 4 Ω | 8 Ω |
| Sensitivity | 94.3 dB | 94.3 dB |
| Frequency Range | 5 kHz | 5 kHz |
| Cone Material | Carbon Fiber | Carbon Fiber |
| Basket Material | Aluminum | Aluminum |
| Magnet Material | Ferrite | Ferrite |
| Power (RMS) | 300W | 300W |
